Description
GoodWe ESA 54kWh Installed Battery System – 9.99kW Single Phase
Store more of your daytime solar with this professionally installed GoodWe ESA home-battery system. The 54kWh nominal package combines 53.10kWh of usable LiFePO₄ storage, a 9.99kW single-phase hybrid inverter and GoodWe SEMS monitoring.
Sale saving: $1,609
Ready to proceed? Have your postcode, supply phase, existing solar size and backup priorities ready.
Clear installed-from offer: $22,986 applies to this 54kWh, 9.99kW single-phase package with a suitable standard on-grid installation and assignment of the applicable federal battery incentive. We confirm the final written scope after reviewing the property, switchboard, access, location and backup requirements.
Choose your GoodWe ESA capacity
The 18kWh package starts at $9,790. Each additional 9kWh nominal battery module adds $3,299, with 8.85kWh additional usable energy. The fixed packages and configurable bundle use the same selling prices.
All five packages use the same 9.99kW single-phase ESA platform. Choose storage around your evening consumption, solar surplus, backup expectations and likely future loads—not simply the largest number.
| Nominal / usable capacity | Battery modules | Normal price | Sale price | Good starting point for |
|---|---|---|---|---|
| 18kWh 17.70kWh usable | 2 × 9kWh nominal | $9,790 | Efficient and moderate-use homes wanting meaningful overnight storage. | |
| 27kWh 26.55kWh usable | 3 × 9kWh nominal | $13,089 | Medium homes with stronger evening loads and more solar to retain. | |
| 36kWh 35.40kWh usable | 4 × 9kWh nominal | $16,388 | Larger households seeking substantial overnight coverage and backup runtime. | |
| 45kWh 44.25kWh usable | 5 × 9kWh nominal | $19,687 | High-use homes with EV charging, pool equipment or heavy evening demand. | |
| 54kWh 53.10kWh usable Selected | 6 × 9kWh nominal | $22,986 | Large homes wanting the maximum capacity in this six-module family. |
Who the 54kWh package suits
Large homes wanting the maximum capacity in this six-module family.
- Homes wanting to store more daytime solar instead of exporting it cheaply.
- Buyers who prefer a coordinated GoodWe inverter, batteries, monitoring and enclosure.
- Customers prepared to have backup loads and switchboard suitability assessed before the final promise is made.
Package and site scope
Included in the advertised package basis
- GoodWe ESA 9.99kW single-phase hybrid inverter
- 6 × GoodWe GW9.0-BAT-D-G20 battery modules (9kWh nominal / 8.85kWh usable each)
- GoodWe ESA enclosure and integrated system components
- Suitable standard on-grid installation within our normal service corridor
- Commissioning, SEMS monitoring setup and customer handover
Assessed and priced for the property
- Backup circuits, changeover and switchboard requirements
- Metering, long cable runs, trenching or difficult access
- Travel, freight and regional installation logistics
- Existing solar integration and network/export constraints
- Any non-standard electrical or civil work
Why consider the GoodWe ESA platform?
One coordinated ecosystem
Hybrid inverter, battery management, storage and monitoring are designed to operate together rather than being assembled from unrelated brands.
Useful 9kWh capacity steps
These packages range from 18kWh to 54kWh nominal capacity (17.70kWh to 53.10kWh usable). Each additional GW9.0-BAT-D-G20 module adds 9kWh nominal capacity and 8.85kWh usable energy.
SEMS monitoring
GoodWe’s SEMS app and portal provide a central view of solar production, household consumption, battery operation and grid exchange.
Backup without vague promises
The ESA can form part of a backup-capable design, but backup performance depends on the switchboard, essential circuits, starting currents and the loads expected to operate together. Pumps, air conditioners, compressors and other inductive loads must be assessed before whole-home or extended backup is promised.
Talk through the 54kWh system
Call with your postcode, supply phase, existing solar size, preferred battery capacity and blackout priorities. We will confirm whether this package is a sensible fit and identify any site work that belongs in the written quote.
Frequently asked questions
Is 54kWh the nominal or usable battery capacity?
54kWh is the total nominal capacity. This package includes 6 × GoodWe GW9.0-BAT-D-G20 modules, each with 9kWh nominal capacity and 8.85kWh usable energy, providing 53.10kWh total usable storage.
Does the sale price cover every installation?
No. It is an installed-from offer for a suitable standard on-grid site. Backup design, switchboard work, difficult access, long cable runs, travel and other non-standard requirements are confirmed in writing.
Can it back up the whole home?
Potentially, but only after the actual loads, phase, switchboard and starting currents have been assessed. A large battery does not by itself guarantee that every appliance can operate together during a blackout.
Why is the inverter described as 9.99kW?
9.99kW is the package’s listed GoodWe ESA single-phase inverter rating. It is commonly described as approximately 10kW.
Specifications
| Package configuration | 54kWh nominal battery capacity with a 9.99kW single-phase inverter |
|---|---|
| WooCommerce SKU | IG-GW-ESA-9.99/48kwh-1P |
| Nominal battery capacity | 54kWh |
| Usable battery energy | 53.10kWh |
| Battery modules | 6 × GoodWe GW9.0-BAT-D-G20 modules (9kWh nominal / 8.85kWh usable each) |
| Inverter | GoodWe ESA 9.99kW single-phase hybrid inverter |
| Chemistry | LiFePO₄ |
| System phase | Single phase |
| Enclosure rating | IP66 |
| Monitoring | GoodWe SEMS app and portal |
| Primary use | On-grid solar storage with a site-assessed backup pathway |
| Rebate | CEC-approved system; incentive eligibility and assignment confirmed for the site |
