GoodWe 5.4kW LYNX Home U Series IP65 Low Voltage Battery LXU5.4 L Photo1

GoodWe 5.4kW LYNX Home U Series IP65 Low Voltage Battery

Original price was: $3,799.00.Current price is: $2,933.00.

Sold Out

SKU: LX U5.4-20 Categories: , , Tags: , ,

Description

GoodWe 5.4kW LYNX Home U Series IP65 Low Voltage Battery

5.4Kwh  51.2V Low voltage battery

Lynx Home U Series: Low-Voltage Lithium Battery for Residential Applications

The Lynx Home U Series is a 51.2V low-voltage lithium battery, designed to deliver superior performance for residential energy storage. Compatible with GoodWe ES and SBP inverters, this series utilizes the safest battery technology available—Lithium Iron Phosphate (LFP).

Key Features:

  • Versatile Applications: Ideal for self-consumption and backup power solutions.
  • Scalable Capacity: Expandable from 5.4kWh to 32.4kWh, meeting diverse energy needs.
  • Simplified Installation: Equipped with Plug and Play wiring and auto-recognition of modules, ensuring faster and easier system setup.
  • Highly Efficient: Maximizes the storage and use of your solar power effectively.

Additional Features

  • Suitable for both indoor and outdoor installation (IP65)
  • For floor and wall installation
  • Emergency power capable (power depends on inverter type)
  • 10-year performance guarantee
  • Plug and play
  • Wall bracket included
  • Max. six LX U5.4-L batteries can be connected in parallel (32.4kWh)
  • Safe & Reliable
  • CEC Approved

Product features Lynx Home U – LX U5.4-L

  • Usable battery capacity: 4.8 kWh
  • Charge/discharge capacity: 2.88 kW Max.
  • Charge/discharge current: 50 A
  • Communication: CAN Temperature range: Discharge: -10°C – 50 °C
  • Temperature range: Charging: 0°C – 50°C
  • Dimensions: 570 x 505 x 175 mm (HxWxD)
  • Weight: 57.0 kg
  • IP: 65
  • Product warranty: 10 years



What is the capacity range of the GoodWe LynX U5.4-20?The GoodWe LX U5.4-20 has a wide capacity range scalable from 5.4–32.4kWh.

Is the GoodWe LX U5.4-20 compatible with other inverters?The GoodWe LX U5.4-20 is compatible with GoodWe ES and SBP inverters.

What is the IP rating of the GoodWe LX U5.4-20?The GoodWe LX U5.4-20 has an IP65 rating, providing protection for outdoor installation safety.





Additional information

Weight57 kg
Dimensions17 × 57 × 50 cm
Chemistry

LiFePO4

Certification

CEC Approved

Use Case

Home Battery, On-grid

Brand

GoodWe

Rebate Eligible

No

Installed Package

No
