Description
Sodium Ion 3.1V 220Ah
Sodium ion batteries are the next generation of energy storage, offering several advantages over traditional lithium-ion batteries. Sodium ion batteries use sodium, a more abundant and eco-friendly element than lithium, reducing the environmental impact and the cost of production. Sodium ion batteries also perform better at low temperatures, have a comparable cycle life, and are safer and more stable.
The 3.1V 220Ah sodium ion battery cell is a high-capacity prismatic cell that can be used for a variety of applications, such as residential solar energy storage, electric vehicles, backup power, and more. The cell has a nominal voltage of 3.1V, a recommended voltage range of 1.5~3.95V, and a maximum continuous current of 100A. The cell weighs 4.4kg and has dimensions of 204 x 174 x 71.5 mm (H x W x D). The cell can deliver 682Wh of energy and has an expected cycle life of 4000 cycles with 80% DOD.
Specification： |
|
Battery Type |
Sodium-ion(SIB) |
Cell Grade |
Brand New Grade A Cell |
Nominal Capacity |
210-220Ah |
Nominal Voltage |
3V |
Internal Resistance |
≤0.5mΩ |
Size (Not include the studs) |
203.7mm X 174mm X 71.25mm |
Weight |
4.7±0.5kg |
Standard Charge Voltage |
3.95 ±0.05 V |
Standard Discharge Voltage |
1.50 ±0.05V |
Standard Charge/Discharge Current |
0.5C |
Max Charge/Discharge Current |
1C |
Max Pulse Charge/Discharge (20s) |
2C |
Charging Temperature |
0℃～45℃ |
Discharging Temperature |
-40℃～60℃ |
Storage Temperature |
-20℃~ 60℃ |
Studs |
M6/Double hole |
If you want to power your future with a clean, efficient, and affordable energy solution, order the 3.1V 220Ah sodium ion battery cell today and enjoy the benefits of sodium ion technology.
Minimum Order QTY 16
