Schneider 16 Amp ACTI9 C60H MCB C Curve 2 Pole
Reliable DC protection for solar arrays and DC distribution systems.
The Schneider Electric Acti9 C60H-DC is a premium 2-pole 16A miniature circuit breaker (MCB), designed for safe and efficient DC circuit protection. With robust 500 VDC operational voltage, 6 kA breaking capacity, and compliance with IEC/EN 60947-2, this breaker delivers reliability in solar PV systems, battery banks, and industrial DC distribution.
Perfect for PV string protection in systems up to 500 VDC.
Key Features
Brand/Series: Schneider Electric Acti9 C60H-DC
Model: A9N61531
Current Rating: 16 A at 25 °C
Poles: 2P (double pole)
Curve: C curve (thermal-magnetic tripping)
Breaking Capacity:
6 kA at 500 V DC
10 kA at 440 V DC
20 kA at 220/250 V DC
Voltage Rating: 500 V DC (operational)
Standards: IEC/EN 60947-2 compliant
Isolation: Suitable for isolation duty (yes, per IEC 60947-2)
Technical Specifications
| Specification | Details |
|---|---|
| Rated Current (In) | 16 A (at 25 °C) |
| Voltage (Ue) | 500 V DC |
| Poles | 2 |
| Tripping Curve | C |
| Breaking Capacity | 6 kA @ 500 V DC 10 kA @ 440 V DC 20 kA @ 220/250 V DC |
| Insulation Voltage (Ui) | 500 V DC |
| Impulse Withstand (Uimp) | 6 kV |
| Utilisation Category | Category A |
| Trip Unit | Thermal-magnetic |
| Frequency | 50/60 Hz |
| Suitability for Isolation | Yes |
| Standards | IEC/EN 60947-2 |
Construction & Durability
| Feature | Details |
|---|---|
| Mounting | 35 mm DIN rail |
| Control | Toggle, ON/OFF indication |
| Padlockable | Yes (in OFF position) |
| Mechanical Durability | 20,000 cycles |
| Operating Temp | –25 °C to +70 °C |
| Storage Temp | –40 °C to +85 °C |
| Pollution Degree | 3 (IEC 60947-2) |
| Overvoltage Category | IV |
| Net Weight | 0.256 kg |
Environmental & Sustainability
Designed under Schneider Electric’s “Use Better, Use Longer, Use Again” campaign
RoHS compliant
Packaging with recycled cardboard
Product Environmental Profile (PEP) available
WEEE compliant for end-of-life handling
Packaging & Warranty
| Package Type | Contents |
|---|---|
| Unit Pack (1 pc) | 8.3 × 7.3 × 3.5 cm, 226 g |
| Box (6 pcs) | 22.6 × 9.2 × 8.3 cm, 1.41 kg |
| Carton (72 pcs) | 40 × 30 × 30 cm, 17.4 kg |
| Warranty | 18 months Schneider Electric_Acti9-C60HDC… |
Applications
Solar PV string protection (up to 500 VDC)
Battery energy storage systems (BESS)
EV charging infrastructure
DC industrial distribution panels
Telecommunications and backup DC systems
Why Choose Schneider Electric Acti9 C60H-DC?
Trusted global brand in electrical protection
Meets international safety standards (IEC/EN 60947-2)
Compact, reliable, and padlockable design for maximum safety
Ready to protect your solar array with Schneider quality? Add to Cart now and secure your DC system.
🔹 16 A version (A9N61531)
Breaker rating: 16 A
Max Isc supported = 16 ÷ 1.25 = 12.8 A
👉 So a 16 A C60H-DC can protect PV strings with Isc ≤ 12.8 A.
🔹 20 A version (A9N61532 – same series) link here
Breaker rating: 20 A
Max Isc supported = 20 ÷ 1.25 = 16 A
👉 So a 20 A C60H-DC can protect PV strings with Isc ≤ 16 A.
