Description
Deye 10.2kWh Low Voltage Battery RW-F10.2
CEC + VPP Approved
Before May 2026 Rebate approx $2700-3000 – Your cost before installation $1000-1300 each.
Installation usually $2000-4000 depending on availability and location and complexity
The RW-F10.2 Lithium Iron Phosphate (LFP) Battery is a safe, high-performance, and eco-friendly energy storage solution for your residential or commercial needs.
Product Description
Advanced Safety & Long Lifespan
Built with cobalt-free LiFePO₄ (LFP) chemistry, this battery offers enhanced safety, thermal stability, and environmental friendliness. The integrated low-voltage safety connection further reduces risk, ensuring peace of mind in all applications.
High Performance & Reliability
Designed for demanding energy storage needs, this battery supports up to 1C charging and 1.2C discharging. It delivers exceptional performance with an impressive lifespan of 6,000 cycles at 90% Depth of Discharge (DoD), backed by a 10-year standard warranty.
Integrated Smart Protection
Equipped with a robust, intelligent Battery Management System (BMS), the battery offers real-time monitoring and comprehensive protection. Its natural air-cooled design, IP65-rated enclosure, and broad operating temperature range (-20°C to 55°C) ensure reliable performance in harsh environments.
Modular & Scalable Design
Easily expandable for larger systems, up to 32 modules can be connected in parallel, offering a total capacity of up to 326 kWh. Ideal for both residential and commercial applications, the modular design helps maximize solar self-consumption and energy independence.
Effortless Integration & Maintenance
Featuring auto-addressing (no DIP switch configuration required), the system supports plug-and-play installation. Remote monitoring, firmware updates, and seamless integration with Deye inverters are available through the Deye platform, enabling a fully stacked all-in-one energy solution.
Sustainable & Eco-Friendly
Constructed using environmentally friendly, non-toxic materials, this battery contributes to a cleaner, greener future without compromising performance.
Flexible Installation Options
The flat, compact form factor supports both wall-mounted (using the included bracket) and floor-standing (with removable base) configurations, saving space and offering greater installation flexibility.
Technical Specifications
Battery Chemistry: LiFePO₄ (LFP)
Nominal Voltage: 51.2V
Nominal Capacity: 200Ah
Nominal Energy: 10.2 kWh
Usable Energy: 9.2 kWh (90% DoD)
Operating Voltage Range: 43.2V – 57.6V
Built-in Circuit Breaker: 125A, 4P, 60V DC
Cycle Life: 6,000 cycles @ 90% DoD
Operating Temperature: -20°C to 55°C
IP Rating: IP65
Max Parallel Modules: 32 (up to 326 kWh)
