Description

Gotion 314AH A- Grade (tested cells)

These are A- Grade pack tested cells, their appearance is excellent, perfect for DIY Solar setups

They have been tested and cycled, The resistance is a bit higher than A Grade. Above 0.2mΩ and below 0.3mΩ

They are priced at half the retail A grade price, because they are not new. The warranty is 12 months, but you can expect to get a few years of non high rate discharge use from these.

Plan for less than 0.33C rate, you could get 10 years or more if you are lucky. But there is no guarantees with this batch.

Manufacturer:

Gotion

Model No.:

314AH- A MINUS

Typical Voltage:

3.2V

Typical Capacity:

314Ah

AC Impedance Resistance:

0.2-0.3mΩ

Life Cycle:

New A Grade is 12000 to 60% EOL which is about 6000 to 80% (these are used so dont expect full life)

Standard Charge/Discharge Current:

0.5C/0.5C

Standard Charge Cut-off Voltage:

3.65V

Standard Discharge Cut-off Voltage:

2.5V

Continuous Charge/Discharge Current:

0.5C/0.5C

Pulse Charge/Discharge Current (60s): 1C

Recommended SOC Window:

10%~90%

Charging Working Temperature:

0℃~55℃

Discharging Working Temperature:

-30℃~60℃

Self Discharging Rate:

<3%

Short Term Storage Temperature (< 1 Month):

-20℃~45℃

Long Term Storage Temperature (< 1 Year):

0℃~35℃

Storage Moisture:

<95%

Cell Dimension:

207.1*71.95*174.8mm

Cell Weight:

5630g

Warranty 30 Days
