Description
GoodWe 5.4kW LYNX Home U Series IP65 Low Voltage Battery
5.4 – 32.4kWh 51.2V Low voltage battery – $600 AUD per KWh
Lynx Home U Series: Low-Voltage Lithium Battery for Residential Applications
The Lynx Home U Series is a 51.2V low-voltage lithium battery, designed to deliver superior performance for residential energy storage. Compatible with GoodWe ES and SBP inverters, this series utilizes the safest battery technology available—Lithium Iron Phosphate (LFP).
Key Features:
- Versatile Applications: Ideal for self-consumption and backup power solutions.
- Scalable Capacity: Expandable from 5.4kWh to 32.4kWh, meeting diverse energy needs.
- Simplified Installation: Equipped with Plug and Play wiring and auto-recognition of modules, ensuring faster and easier system setup.
- Highly Efficient: Maximizes the storage and use of your solar power effectively.
Additional Features
- Suitable for both indoor and outdoor installation (IP65)
- For floor and wall installation
- Emergency power capable (power depends on inverter type)
- 10-year performance guarantee
- Plug and play
- Wall bracket included
- Max. six LX U5.4-L batteries can be connected in parallel (32.4kWh)
- Safe & Reliable
- CEC Approved
Product features Lynx Home U – LX U5.4-L
- Usable battery capacity: 4.8 kWh
- Charge/discharge capacity: 2.88 kW Max.
- Charge/discharge current: 50 A
- Communication: CAN Temperature range: Discharge: -10°C – 50 °C
- Temperature range: Charging: 0°C – 50°C
- Dimensions: 570 x 505 x 175 mm (HxWxD)
- Weight: 57.0 kg
- IP: 65
- Product warranty: 10 years
Compatible with Goodwe Inverter Models
ES Series
EM Series
BP Series
SBP Series
