Description
Deye Hybrid Off-Grid Power Bundles
5 kW | 6 kW | 8 kW | 10 kW | 12 kW | 16 kW Single Phase – AU Models
The Deye Hybrid Off-Grid Bundle combines premium Deye single-phase hybrid inverters with your choice of high-performance Lifepro LiFePO₄ battery storage.
Configure to suit your exact needs – from a single 5 kW inverter with one battery, to large-scale systems with up to 15 batteries for massive storage capacity.
Inverter Options – Deye Hybrid AU Series
Models: 5 kW, 6 kW, 8 kW, 10 kW, 12 kW, 16 kW (Single Phase, Australian models)
High efficiency hybrid design for off-grid or future on-grid connection
Wide PV input voltage range and high MPPT tracking accuracy
Seamless switchover between solar, battery, and generator power
Advanced monitoring via Wi-Fi or LAN
Battery Options
1. Lifepro 5.12 kWh 51.2 V 100 Ah LiFePO₄ Rack Battery
Premium small-form rack battery featuring EVE LF100LA A Grade cells and a PACE BMS with touchscreen, Bluetooth, and Wi-Fi.
Built for longevity, ease of management, and exceptional inverter compatibility.
Key Features:
5.12 kWh usable capacity | 100 A continuous discharge
5000+ cycles @ 80% DoD – 10+ years daily cycling
Tier-One A Grade EVE LF100LA prismatic cells
Built-in DC 125 A circuit breaker
Touchscreen BMS with Bluetooth App + Wi-Fi
Supports RS485 communication with Deye, Victron, Growatt & more
20 A current limit control for cell longevity under heavy cycling
Parallel up to 64 units (professional install required)
Specifications:
| Parameter | Value |
|---|---|
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 102 Ah |
| Energy | 5.12 kWh |
| Cell Type | EVE LF100LA (A Grade) |
| Cycle Life | 5000 cycles @ 80% DoD |
| Max Continuous Current | 100 A |
| Recommended Continuous Current | 50 A |
| BMS Type | PACE BMS w/ Touchscreen, Bluetooth, Wi-Fi |
| Enclosure | 3U Rack Case |
| Weight | 47 kg |
| Parallel Capability | Up to 64 units |
2. Lifepro 16 kWh 51.2 V 314 Ah LiFePO₄ Battery
High-capacity off-grid battery featuring EVE MB31 A Grade cells and a JK 200 A BMS with 2 A active balancing.
Ideal for large systems, heavy loads, and long autonomy.
Key Features:
16 kWh usable capacity | 200 A continuous discharge (300 A surge 15 s)
8000 cycles @ 80% DoD – 10+ years daily cycling
Automotive-grade EVE MB31 cells
Active balancing (2 A) for cell longevity
User-repairable modular design – not welded, easy to service
Built-in circuit breaker for safety
Parallel up to 3 units per stack for 48 kWh
Specifications:
| Parameter | Value |
|---|---|
| Nominal Voltage | 51.2 V |
| Nominal Capacity | 314 Ah |
| Energy | 16 kWh |
| Cell Type | EVE MB31 (A Grade) |
| Cycle Life | 8000 cycles @ 80% DoD |
| Max Continuous Current | 200 A |
| Surge Current (15 s) | 300 A |
| BMS Type | JK BMS w/ 2 A Active Balancing |
| Dimensions (L × W × H) | 750 × 439 × 252 mm |
| Weight | 110 kg |
| Parallel Capability | Up to 3 per stack (48 kWh) |
Why Choose This Bundle?
Scalable – Choose inverter size & battery capacity to match your energy needs
Premium Components – Tier-One A Grade LiFePO₄ cells + high-end BMS
Future-Ready – Designed for off-grid now, with compatibility for on-grid later
Long Life – 10+ years design life with proper cycling
High Efficiency – Up to 97% round-trip battery efficiency
