Description
12V to 56V DC Converter
MODELS AVAILABLE
12V to 56V – 3A
12V to 56V – 5A
DELIVERY TIME
Special Order Item – 12-20 Days – Its not stocked in our warehouse.
12V to 56V – 3A |
Specification |
|---|---|
Efficiency |
Up to 95% |
Input Voltage |
11-16V DC |
Output Voltage |
56V |
Output Current |
3A |
Ripple |
200mVp |
Line Regulation |
±0.2% |
Load Regulation |
±0.2% |
Voltage Accuracy |
±1.5% |
Enclosures |
IP68 |
Dimension |
74x74x30mm |
Net Weight |
0.28kg |
Operating Temperature |
-40~85°C |
Certificates |
CE, ROHS |
Warranty |
1 year |
12V to 56V – 5A |
Specification |
|---|---|
Efficiency |
Up to 95% |
Input Voltage |
12V/24V DC |
Output Voltage |
56V |
Output Current |
5A |
Ripple |
200mVp |
Line Regulation |
±0.2% |
Load Regulation |
±0.2% |
Voltage Accuracy |
±1.5% |
Enclosures |
IP68 |
Dimension |
118x80x28mm |
Net Weight |
0.8kg |
Operating Temperature |
-40~85°C |
Certificates |
CE, ROHS |
Warranty |
1 years |
