Victron Phoenix Inverter 48/5000 230V Smart
The Victron Phoenix Inverter 48/5000 230V Smart is a high-performance inverter designed to convert DC power from 48V batteries into reliable 230V AC power, suitable for off-grid and backup systems. This unit provides 5000VA of continuous power, making it ideal for powering a variety of appliances in vehicles, boats, caravans, and homes. The inverter features Bluetooth connectivity, allowing users to easily configure and monitor settings through the VictronConnect app on a smartphone or tablet.
Key Features
- Built-in Bluetooth: Configure settings such as voltage cut-off, alarms, output voltage, frequency, and more via the VictronConnect app.
- High Peak Power: Capable of handling power surges up to 10,000W, perfect for starting demanding loads like power tools or appliances.
- ECO Mode: Reduces energy consumption by switching to standby when the load is below a preset threshold.
- VE.Direct Port: Enables connection to a computer for configuration and monitoring via the VE.Direct to USB cable.
- Proven Reliability: The unit features a toroidal transformer for stable sine-wave output and is protected against short circuits and overheating.
Why You Should Buy
- Versatility: Ideal for off-grid applications in boats, caravans, RVs, or homes, offering flexibility to power common household appliances.
- Remote Monitoring and Control: The built-in Bluetooth allows you to monitor and configure the inverter remotely, providing convenience and peace of mind.
- High Start-Up Power: Its ability to handle surges ensures that even power-hungry devices like compressors or large appliances start without any issues.
| Phoenix Smart Inverter | 48/5000 |
| Parallel and 3-phase operation | No |
| Inverter | |
| Input voltage range | 37.2 – 68 V |
| Output | Output voltage: 230 VAC ±2% 50 Hz or 60 Hz ± 0.1 % (1) |
| Cont. output power at 25 ºC (1) | 5000 VA |
| Cont. output power at 25 ºC | 4000 W |
| Cont. output power at 40 ºC | 3700 W |
| Cont. output power at 65 ºC | 2800 W |
| Peak power | 10000 W |
| Dynamic (load dependent) DC low shut down (fully configurable) |
Dynamic cut-off |
| Max. efficiency | 96 % |
| Zero load power | 20 W |
| Zero load power in ECO mode | 3.2 W |
| General | |
| Programmable relay (2) | Yes |
| Stop & start power ECO-mode | adjustable |
| Protection (3) | a – g |
| Bluetooth wireless communication | For remote monitoring and system integration |
| VE.Direct communication port | For remote monitoring and system integration |
| Remote on-off | Yes |
| Common Characteristics | Operating temperature range: -40 to +65 ºC (fan assisted cooling) Humidity (non-condensing): max 95 % |
| Enclosure | |
| Common Characteristics | Material & Colour: steel (blue RAL 5012; and black RAL 9017) Protection category: IP21 |
| Battery-connection | M8 bolts |
| 230 VAC-connection | Screw terminals |
| Weight | 28 kg |
| Dimensions (hxwxd) | 555 x 295 x 160 mm |
| Standards | |
| Safety | EN 60335-1 |
| Emission Immunity | EN 55014-1 / EN 55014-2/ EN-IEC 61000-6-1 / EN-IEC 61000-6-2 / EN-IEC 61000-6-3 |
| Automotive Directive | ECE R10-5 |
- Non-linear Load, Crest Factor 3:1
- Programmable Relay:
- Can be set for:
- General alarm
- DC under voltage
- Genset start/stop function
- AC Rating: 230 V / 4 A
- DC Rating: 4 A / 35 VDC, 1 A / 60 VDC
- Can be set for:
- Protection Key:
- a) Output short circuit
- b) Overload
- c) Battery voltage too high
- d) Battery voltage too low
- e) Temperature too high
- f) 230 VAC on inverter output
- g) Input voltage ripple too high
| Barcode # | 8719076047940 |
| MPN # | PIN482500000 |
