Description

Victron MultiPlus-II 48/15000/200-100 Inverter Charger PMP483150000

The Victron MultiPlus-II 48/15000/200-100 is a robust, high-capacity inverter/charger designed for demanding off-grid, marine, and backup energy applications. Combining a powerful true sine wave inverter, sophisticated battery charger, and high-speed AC transfer switch in one compact enclosure, it provides seamless energy management for both residential and commercial systems.

Key Features

• High Continuous Power Output
  Delivers 15,000 VA (12,000 W) continuous power, with a surge capacity up to 27,000 W to handle heavy startup loads.

• Intelligent Battery Charging
  Features a 200 A charger suitable for lithium, AGM, and other battery types. Adaptive charging helps prolong battery lifespan.

• PowerAssist Technology
  Supports limited AC sources like generators or grid connections by boosting available power using battery reserves.

• Seamless UPS Functionality
  Instantly takes over power supply during outages, ensuring uninterrupted operation for sensitive electronics.

• ESS-Ready Integration
  Fully compatible with energy storage systems, allowing smart energy usage, grid feedback, and solar optimization.

• Remote Monitoring & Configuration
  Easily monitor and manage your system from anywhere using Victron’s remote management platform when paired with GX devices.

Specifications

• Battery Voltage: 48 V

• Continuous Power: 15,000 VA (12,000 W)

• Peak Power: 27,000 W

• Charger Current: 200 A

• AC Input Current: 100 A max

• Efficiency: Up to 95%

• Dimensions: 810 x 405 x 217 mm

• Weight: ~80 kg

• AC Output: Dual AC outputs (UPS & non-critical loads)

Advanced Capabilities

• Dual AC Outputs
  One for essential loads with UPS support and another for non-essential loads.

• Parallel and Three-Phase Support
  Scalable for larger systems by connecting multiple units in parallel or three-phase configurations.

• Programmable Relays and Settings
  Fully configurable to meet unique system requirements, including generator auto-start and load shedding.

This inverter/charger is ideal for larger off-grid homes, mobile setups, or commercial installations where high reliability and energy efficiency are critical.
