Hithium 314ah 3.2v LFP Prismatic A Grade
Warranty is 5 Years
This product is not stocked
Shipping, and Delivery are additional, these cells will be BRAND NEW and A Grade
The Minimum order Qty is 16 cells, the ETD is 6-8 weeks
Specially optimised for use in stationary battery storage systems with the highest requirements on safety, reliability and performance. Suitable e.g. for industrial, utility, and grid serving applications.
This cell is optimised heavily for long life, used in ESS and high end battery storage products. Over the past 2 years, there has been significant upgrades to the production techniques and technology of LFP cells. This is why the 8000, 10,000, 11,000, 12,000 and cycle life cells are starting to show up
- Product certifications:
IEC 62619, UL 1973, UL 9540A, UN 38.3 - Company certifications:
ISO 9001, ISO 14001, ISO 45001 - Environmental Compliance: ROHS, REACH
High safety
- Hithium-developed prismatic LFP cell with high thermal stability
- Passes crush and nail penetration test
- Ultra wide operating temperature range
Low LCOS (Levelised Cost of Storage)
- Long life cycle > 11.000 cycles at 0,5 P/0,5 P 70 % SOH *1,2,3
due to advanced materials and process technologies
GENERAL:
| Nominal Capacity | 314 Ah |
| Nominal Energy | 1,004.8 Wh |
| Cell Chemistry | LiFePo4 (LFP) |
| Nominal Cycles | > 11.000 |
| Gravimetric energy density | > 175Wh/kg |
| Volumetric energy density | > 360 Wh/l |
| Industry Standard (Type) | LFP71173207 |
ELECTRICAL:
| Nominal Voltage | 3,2 V |
| Operating Voltage | T > 0°C : 2,50 … 3,65 V T ≤ 0°C : 2,00 … 3,65 V |
| AC Resistance (1 kHz) | 0,18 mΩ |
| Max. self discharge rate | 3 % / month |
| Nominal SOC at delivery | 27 % |
| Max. continuous charge rate | 1P |
| Max. continuous discharge rate | 1P |
MECHANICAL:
| Dimensions (L x W x H) | 174,7 x 71,65 x 207,11 mm |
| Type | prismatic |
| Weight | 5,43 kg +/- 0,2 |
| Volume | 2,59 l |
TEMPERATURE RANGE:
| Charging | 0 °C … 60 °C 5 |
| Discharging | -30 °C … 60 °C 5 |
| Storing (recommended) | -20 °C … 35 °C (5 °C … 35 °C) 5 |
PRODUCT CERTIFICATIONS:
| Certificates and Reports | IEC 62619, UL 1973, UL 9540A, UN 38.3 |
ENVIRONMENTAL:
| Compliance | ROHS, REACH |
| Cobalt free |
COMPANY CERTIFICATIONS:
| ISO 9001, ISO 14001, ISO 45001 |
1 0,5 P/0,5 P
2 25°C +/- 2,0
3 70% SoH
4 27% SOC
5 ambient temperature
QR is Zero’d out on this batch (standard practice for non A+ Grade cells)
